BRAVO 40 | 40 Amp MPPT Solar Charge Controller | Premium 40A 12V/24V MPPT Solar Controller for RVs, Trailers, Campers, Vans, Boats, Off-Grid | Awarded #1 Solar Controller 2025 | UL 1741 Certified
SKU:
RS-MPPT40P
Sale price
$159.99
Regular price
$199.99
Unit price
BRAVO 40 | 40 Amp MPPT Solar Charge Controller | Premium 40A 12V/24V MPPT Solar Controller for RVs, Trailers, Campers, Vans, Boats, Off-Grid | Awarded #1 Solar Controller 2025 | UL 1741 Certified is backordered and will ship as soon as it is back in stock.
Specifications & Downloads
Specifications & Downloads
Product Images
-
System Nominal Voltage12/24V Auto
-
Max. PV Open Circuit Voltage100V DC
-
Charging TechnologyMPPT
-
Max PV Charging Current40A
-
Max. Recommended PV Input Power600 Watt (12V) / 1200 Watt (24V)
-
Charge Conversion Efficiency≤98%
-
MPPT Tracking Efficiency>99.5%
-
Battery Type PresetCrystal, Gel, AGM, WET, Calcium / LCO, LFP, LTO
-
Housing Case ColorBlack / Grey
-
IP GradeIP43 for Inside PCBA, IP22 for Connection Area
-
Dimensions (L × W × H)7.7 × 5.5 × 2.9 in
-
Net Weight2.58lb
-
Package Dimensions10 × 7 × 5 in
-
Gross Weight4 lb
Customer Support:
Call 800-831-9889 to speak with one of our representatives.
Email: support@richsolar.com
Phone Hours: Mon-Fri 9am-5pm PST
Local Pickup Available at Request:
1900 Mountain Ave
Norco, CA 92860
Warning: Cancer risk and reproductive harm. www.P65Warnings.ca.gov
BRAVO 40 | 40 Amp MPPT Solar Charge Controller | Premium 40A 12V/24...
Sale price
$159.99
Regular price
$199.99
Unit price
SKU:
RS-MPPT40P
Sale price
$159.99
Regular price
$199.99
Unit price
BRAVO 40 | 40 Amp MPPT Solar Charge Controller | Premium 40A 12V/24V MPPT Solar Controller for RVs, Trailers, Campers, Vans, Boats, Off-Grid | Awarded #1 Solar Controller 2025 | UL 1741 Certified is backordered and will ship as soon as it is back in stock.
Payment & Security
Payment methods
Your payment information is processed securely. We do not store credit card details nor have access to your credit card information.
Features
Efficient Solar Charging
- Over 99.5% MPPT Tracking Efficiency: Maximizes solar energy harvest under changing sunlight conditions.
- Up to 98% Charge Conversion Efficiency: Converts more solar power into usable battery charging energy.
- Supports up to 1200W PV Input: Handles larger solar arrays for faster battery charging.
Flexible System Compatibility
- 12V/24V Auto Detection: Automatically identifies the system voltage during installation.
- 100V Max PV Open Circuit Voltage: Supports flexible solar panel configurations and system expansion.
- Supports Multiple Battery Types: Compatible with Crystal, GEL, AGM, Flooded (WET), Calcium, LCO, LFP, and LTO batteries.
Smart Monitoring
- Built-In Bluetooth Monitoring: Monitor real-time charging status on your smartphone via the SmartLife App.
- LCD Display: View solar input, battery status, and charging information.
- Optional Accessories: Compatible with an optional remote meter and battery temperature sensor.
Comprehensive Reliability
- Certified to UL 1741, FCC, CE, and RoHS standards.
- Advanced Electronic Protection: Protects against over-voltage, reverse discharge, and circuit faults.
- Conformal Coated Circuit Board: Improves long-term durability in demanding environments.
Specifications
- System Nominal Voltage: 12/24V Auto
- Max. PV Open Circuit Voltage: 100V DC
- Charging Technology: MPPT
- Max PV Charging Current: 40A
- Max. Recommended PV Input Power: 600 Watt (12V) / 1200 Watt (24V)
- Charge Conversion Efficiency: ≤98%
- MPPT Tracking Efficiency: >99.5%
- Battery Type Preset: Crystal, Gel, AGM, WET, Calcium / LCO, LFP, LTO
- Housing Case Color: Black / Grey
- IP Grade: IP43 for Inside PCBA, IP22 for Connection Area
-
Dimensions (L × W × H): 7.7 × 5.5 × 2.9 in
-
Net Weight: 2.58lb
-
Package Dimensions: 10 × 7 × 5 in
- Gross Weight: 4 lb
What is Basic Solar System?
Customer Reviews
Overall rating: 4.4 / 5 from 7 reviews.
easy to install. battery codes setup is confusing. numbers do not readily show type of battery type. a chart would be nice not a cycle with micro print type. rich solar does not have an app access to this unit. third party also does not list anything solar.
Works really well. I like the way it displays what you want to see and does not switch back to a default. I have the 40 amp and 60 amp set up working together and both are great.
The newer of the Rich Solar 40A charge controller (BRAVO 40) drops the load terminals compared to the prior version. This was not well described in the product documentation from the website. It also only interfaces with the newer Rich Solar Bluetooth application which is another change fore the prior version of the same controller. It takes up a smaller installation footprint. Easy to install, does what a 40 Amp controller should do.
Works great, built in bluetooth is a nice touch.
Works great better voltage handling
Bought a marine 105 AH AGM battery from Orielly. Set up the system and it charge up fully in 20 minutes. Bad ass.
