60 Amp MPPT Solar Charge Controller

Features

Efficient MPPT Solar Charging

• Up to 99% MPPT Tracking Efficiency: Maximizes solar energy harvest under changing sunlight conditions.

• Up to 98% Conversion Efficiency: Converts more solar power into usable battery charging energy.

• Supports up to 3200W PV Input: Recommended for solar arrays up to 800W (12V), 1600W (24V), 2400W (36V), or 3200W (48V).

Flexible System Compatibility

• 12V/24V/36V/48V Auto Detection: Automatically identifies the system voltage during installation.

• 150V Max Solar Input Voltage: Supports flexible solar panel configurations.

• Supports Multiple Battery Types: Compatible with Sealed, Gel, Flooded, and Lithium batteries.

User-Friendly Operation

• LCD Display with LED Indicators: Displays charging status, battery information, operating parameters, and fault codes.

• Bluetooth Ready: Supports the optional BT-1 Bluetooth module via the RS232
• communication port for wireless monitoring.

• Die-Cast Aluminum Housing: Provides efficient heat dissipation for reliable operation.

Comprehensive Reliability

• Advanced Electronic Protection: Protects against reverse polarity, overcharging, overload, and short circuit.

• Lithium Battery Recovery: Capable of charging over-discharged lithium batteries.

• Designed for Long-Term Reliability: Durable construction for demanding off-grid applications.

Specifications

• Nominal System Voltage: 12V/24V/36V/48V Auto

• Rated Battery Current: 60A

• Rated Load Current: 20A

• Max Solar Input Voltage: 150V(77℉), 145V(-13℉)

• Max Solar Input Power: 800W/12V; 1600W/24V; 2400W/36V; 3200W/48V

• Charge Circuit Voltage Drop: ≤0.26V

• Discharge Circuit Voltage Drop: ≤0.15V

• Operating Temperature: -31°F to 113°F

• Max Terminal Size: <11mm

• Overall Dimensions: 11.2 x 8.1 x 3.7 in

• Net Weight: 7.94 lb
