BRAVO FLUSH 40 | 40 Amp Flush Mount MPPT Solar Charge Controller | Premium 40A 12V/24V PWM Flush Mount Solar Controller for RVs, Trailers, Campers, Vans, Boats, Off-Grid | #1 Flush Mount MPPT Solar Controller
BRAVO FLUSH 40 | 40 Amp Flush Mount MPPT Solar Charge Controller | Premium 40A 12V/24V PWM Flush Mount Solar Controller for RVs, Trailers, Campers, Vans, Boats, Off-Grid | #1 Flush Mount MPPT Solar Controller is backordered and will ship as soon as it is back in stock.
Customer Support:
Call 800-831-9889 to speak with one of our representatives.
Email: support@richsolar.com
Phone Hours: Mon-Fri 9am-5pm PST
Local Pickup Available at Request:
1900 Mountain Ave,
Norco, CA 92860
Warning: Cancer risk and reproductive harm. www.P65Warnings.ca.gov
BRAVO FLUSH 40 | 40 Amp Flush Mount MPPT Solar Charge Controller | ...
Payment & Security
Payment methods
Your payment information is processed securely. We do not store credit card details nor have access to your credit card information.
Features
- PV open circuit voltage up to 100V.
- The latest Maximum Power Point Tracking (MPPT) algorithm.
- Unique multiple peaks detected technology for MPPT.
- MPPT tracking efficiency above 99.5%.
- Wider MPP operating voltage range.
- Common negative grounding connection.
- Suit for most rechargeable batteries, up to 9 battery types preset plus custom setting.
- Extensive internal electronics in-circuit protection.
- Reliable operating safety protection: overcharging or undercharging protection, short circuit protection, reverse polarity protection, and thermal protection.
- Automatically detect 12V or 24V DC system voltages.
- Unique and concise LED bar to indicate the solar status and battery charging condition.
- Large and informative display interface to show solar parameters, battery charging parameters, battery type, battery temperature, custom presetting faulty codes, etc.
- Provides plug-in remote digital display meter (Optional).
- Provides external battery temperature sensor (Optional).
- Splash-proof IP43.
- Rubber mask for connecting terminal’s protection.
- Conformal coating for internal boards.
- Designed according to UL1741, EN/IEC 62109-1; EMI standard: EN61000-6-1/EN61000-6-3 and FCC standard: 47 CFR Part 15, Subpart B.
Specifications
- Max. PV Open Circuit Voltage: 100 VDC
- Max. Normal Input PV Voltage: 92 VDC
- Max. PV Input Current: 40 AMP
- Max. PV Short Circuit Current: 45 AMP
- Max. Conversion Efficiency: 98%
- Min. Tracking Efficiency: 99.5%
- Nominal PV Power: 600W@12V/1200W@24V
- Min. Battery Start Charging Voltage: 5 VDC
- Soft Start Charging Voltage: 5~10±2
- Soft Start Charging Current: 20 AMP
- Max. Bulk Charge: 40 AMP
- Controller Material: Plastic, PC
- Mounting: Surface Mounting
- IP Grade: IP43
- Net Weight: 1.87 lb
- Operating Temperature: -13 ~ 122 ℉
- Storage Temperature: -40 ~ 185 ℉
- Operating Humidity Range: 0-85% RH
