MEGA 430 BIFACIAL | 430W Bifacial N-Type Solar Panel | Premium 24V Grid-tie or Off-grid Solar Panel for Residential, Commercial, Agriculture | 25-Year Output Warranty | UL Certified
MEGA 430 BIFACIAL | 430W Bifacial N-Type Solar Panel | Premium 24V Grid-tie or Off-grid Solar Panel for Residential, Commercial, Agriculture | 25-Year Output Warranty | UL Certified - 8 Solar Panels is backordered and will ship as soon as it is back in stock.
Customer Support:
Call 800-831-9889 to speak with one of our representatives.
Email: support@richsolar.com
Phone Hours: Mon-Fri 9am-5pm PST
Local Pickup Available at Request:
1900 Mountain Ave
Norco, CA 92860
Warning: Cancer risk and reproductive harm. www.P65Warnings.ca.gov
MEGA 430 BIFACIAL | 430W Bifacial N-Type Solar Panel | Premium 24V ...
Payment & Security
Payment methods
Your payment information is processed securely. We do not store credit card details nor have access to your credit card information.
Features
Unmatched Performance
- 22.0% Module Efficiency: Industry-leading conversion with +5W positive tolerance
- 430W Maximum Output: High power density reduces BOS (Balance of System) costs
- -0.30%/°C Pmax Coefficient: Superior heat resistance (up to 185℉) for stable desert performance
Breakthrough Cell Technology
- N-TOPCon Cells: 10–30% higher yield than conventional P-type modules
- Zero LID: Minimal 1% first-year degradation for lasting output
- Passivated Contact Design minimizes power degradation
Advanced Bifacial Design
- 80%+ Bifaciality Factor maximizes rear-side energy harvest
- 15–25% Additional Yield in standard ground-mounted systems
- Dual-Glass Construction: 94% light transmittance for maximum albedo utilization
Military-Grade Durability
- 5400Pa Front Load: Certified for heavy snow regions
- 2400Pa Wind Load: Withstands hurricane-force winds
- IP68 Protection: Fully submersible junction box
Versatile Applications
- BIPV (Building-Integrated Photovoltaics)
- Vertical Mounting Systems
- Extreme Environments: Coastal / Desert / Arctic (up to -40℉)
Intelligent Integration
- 1500V System Voltage Ready: Reduces wiring costs
- MC4-Compatible Connectors for plug-and-play installation
- 30A Fuse Rating: Meets global safety standards
Specifications
- Model: RS-M430BF
- Peak Power: 430W
- Max Efficiency: 22.0%
- Module Efficiency: 19.0%
- Max Power Voltage (Vmp): 31.9V
- Max Power Current (Imp): 13.5A
- Open Circuit Voltage (Voc): 37.4V
- Short Circuit Current (Isc): 14.7A
- Max Series Fuse Rating: 30A
- Maximum System Voltage: 1500VDC
- Cell Type: Monocrystalline
- Number of Cells: 6 x 18 (108 cells total)
- Front Glass: 3.2 mm Tempered Glass
- Frame Material: Anodized Aluminium Alloy
- Operating Temperature: -40°F to 185°F (-40℃ to +85℃)
- Dimensions: 67.8" L × 44.7" W × 1.2" H (1722 × 1134 × 30 mm)
- Weight: 45.4 lb (20.6 kg)
