BRAVO 50 | 50 Amp MPPT Solar Charge Controller | Premier 50A 12V/24V MPPT Solar Controller for RVs, Trailers, Campers, Vans, Boats, Off-Grid | Awarded #1 Solar Controller 2025

Features

• True MPPT
• Tracking Efficiency Above 99.5%
• Charge Conversion Efficiency as High as 98%
• 12V / 24V DC System Self-Adaptation
• Reverse Discharge Protection
• Targeted for Accuracy
• Overvoltage Protection
• Common Negative Connection
• Charging Data Storage
• Conformal Coating for Inside Board
• Designed According to UL1741, EN/IEC 62109-1
• In-house Design and Manufacture
• Extensive Internal Electronics In-Circuit Protections and Safety Protections
• Targeted for Lead Acid Batteries: Gel, AGM, WET, CRYSTAL, CALCIUM Batteries Type Selections
• Targeted for Lithium Batteries: LiFePO4, LTO (Lithium Titanate Oxide), LCO Batteries Type Selections

Specifications

• System Nominal Voltage: 12/24V Auto
• Max PV Open Circuit Voltage: 100VOC
• Charging Technology: MPPT
• Max PV Charging Current: 50A
• Max. Recommended PV Input Power: 700 Watt (12V) / 1400 Watt (24V)
• Battery Type Preset: Crystal, Gel, AGM, WET, Calcium / LCO, LFP, LTO
• Housing Case Color: Black / Grey
• IP Grade: IP43 for Inside PCBA, IP22 for Connection Area
• Net Weight: 1.40kg / 3.09lb
• Dimensions (L*W*H): 195*140*74 mm / 7.7*5.5*2.9 in
