BRAVO 30 | 30 Amp MPPT Solar Charge Controller | Premium 30A 12V/24V MPPT Solar Controller for RVs, Trailers, Campers, Vans, Boats, Off-Grid | Awarded #1 Solar Controller 2025

Features

1. Advanced MPPT Technology

• True MPPT with the latest algorithm (tracking efficiency >99.5%)

• Multi-peak Detection for optimal tracking in shaded conditions

• High charge conversion efficiency (up to 98%)

2. Intelligent System Compatibility

• Auto-detects 12V/24V systems – seamless integration
• Supports 8+ battery types: Lead-Acid (Gel, AGM, Wet, Crystal, Calcium) and Lithium (LiFePO₄, LTO, LCO)
• Optional battery temp sensor for precision charging


3. Advanced Protection System

• Triple safety protection: Over-voltage/Reverse discharge/Short-circuit

• Weatherproof construction: IP43-rated internal components, IP22-protected connection ports
• Lithium Battery Activation: Recovery for Lithium Batteries


4. Precision Charging Control

• Customizable charge parameters

• Performance data recording

• Proprietary battery optimization algorithms

5. Intelligent Monitoring System

• LCD shows: Real-time solar input, Battery health metrics, Custom parameter settings
• Visual LED status bar for instant diagnostics
• Bluetooth & remote display options for wireless control

Specifications

• System Nominal Voltage: 12/24V Auto
• Max. PV Open Circuit Voltage: 100VOC
• Charging Technology: MPPT
• Max PV Charging Current: 30A
• Charge Conversion Efficiency: ≤98%
• MPPT Tracking Efficiency: >99.5%
• Max. Recommended PV Input Power: 500W (12V) / 1000W (24V)
• Battery Type Preset: Crystal, Gel, AGM, WET, Calcium / LCO, LFP, LTO
• Housing Case Color: Black / Grey
• Protection Rating: IP43 for Inside PCBA, IP22 for Connection Area
• Net Weight: 1.10kg / 2.43lb
• Dimensions (L*W*H): 180*140*73mm / 7.0*5.5*2.9in
