Solar PV DC Quick Disconnect Switch | Solar Array DC Quick Disconnect Switch | 1500 Volt 40 Amp | 4 Pole 2 Strings | Easy to Install | UL 508I Certified
SKU:
RS-i4
Regular price
$109.99
Unit price
Solar PV DC Quick Disconnect Switch | Solar Array DC Quick Disconnect Switch | 1500 Volt 40 Amp | 4 Pole 2 Strings | Easy to Install | UL 508I Certified is backordered and will ship as soon as it is back in stock.
Customer Support:
Call 800-831-9889 to speak with one of our representatives.
Email: support@richsolar.com
Phone Hours: Mon-Fri 9am-5pm PST
Local Pickup Available at Request:
1900 Mountain Ave,
Norco, CA 92860
Warning: Cancer risk and reproductive harm. www.P65Warnings.ca.gov
Solar PV DC Quick Disconnect Switch | Solar Array DC Quick Disconne...
Regular price
$109.99
Unit price
SKU:
RS-i4
Regular price
$109.99
Unit price
Solar PV DC Quick Disconnect Switch | Solar Array DC Quick Disconnect Switch | 1500 Volt 40 Amp | 4 Pole 2 Strings | Easy to Install | UL 508I Certified is backordered and will ship as soon as it is back in stock.
Payment & Security
Payment methods
Your payment information is processed securely. We do not store credit card details nor have access to your credit card information.
Features
- Quick DC Disconnect: Safely isolates your solar array from connected equipment.
- Fast Arc Suppression: Disconnects load circuits in under 3 milliseconds.
- Outdoor Ready: IP66NW rated for reliable outdoor use.
- Secure Operation: SAFE-LOCK design helps prevent tampering.
- Easy Installation: Convenient connections for quick setup.
- Versatile Use: Designed for off-grid and grid-tied solar systems.
- UL 508I Certified: Certified for safe and reliable DC disconnecting in photovoltaic systems.
AWARNING
- DO NOT mix MC4 connectors from different manufacturers or brands.
- Use only the connectors and terminals supplied with this product. Crimp the terminals using the specified crimping tool, and ensure each connector is fully inserted and securely locked with an audible “click.”
- Failure to follow these instructions may result in overheating, fire, or equipment damage.The installer assumes full responsibility for any damage or loss resulting from improper installation or failure to follow these instructions.
Specifications
-
Rated Insulation Voltage (Ui): 1500V
- Rated Thermal Current (Ith): 40A
- Poles / Circuit: 4P in series
- Supported PV Strings: 2 PV strings
- Impulse Withstand Voltage: 8 kV
- IP Rating: IP66NW
- Arc Suppression Time: <3 ms
- Operating Temperature: -40℉ to 158℉
- Housing Material: Flame-retardant PC (UL94 V-0)
- Dimensions (HxWxD): 7.1x6.8x4.3 in
- Net Weight: 1.6lb
- Certifications: CE, UL 508I
- Warranty: 3 years
-
Package Dimensions: 8 × 5 × 8 in
- Gross Weight: 3 lb
Customer Reviews
Overall rating: 5.0 / 5 from 6 reviews.
Very quick with delivery and got the order perfect. Great company to work with
I had trouble with my Quick Disconnect Switch. Tech support was very helpful in solving by problem!
A great product.
The pictures have been updated to correctly show the in's and out's. These have proven to be more convenient to me than I expected.
Nicely built. However, the picture here is not correct. It shows both 'in's on the left side and both 'outs' on the right side. I received 3 of these and all 3 show that both that the top left and top right are 'in's, and the bottom left and bottom right are 'out's. So heads up if that matters to you. It doesn't for me. Mine ordered and received Nov, 2023.
