1 5

300 Watt Solar Kit

SKU: RS-K3004
$599.99

Specifications & Downloads

Product Images

Full Specification:

MEGA 100 Solar Panel

Download

BRAVO 40 40 Amp MPPT Solar Charge Controller

Download

User Manual:

BRAVO 40 40 Amp MPPT Solar Charge Controller

Download

Warranty

Check out our full Warranty page here for more information.

Customer Support:

Call 800-831-9889 to speak with one of our representatives.

Email: support@richsolar.com

Phone Hours: Mon-Fri 9am-5pm PST

Local Pickup Available at Request:

1900 Mountain Ave,
Norco, CA 92860

Warning: Cancer risk and reproductive harm. www.P65Warnings.ca.gov

Payment & Security

Payment methods

  • Ach Direct Debit
  • Amazon
  • American Express
  • Apple Pay
  • Diners Club
  • Discover
  • Google Pay
  • Mastercard
  • PayPal
  • Shop Pay
  • Visa

Your payment information is processed securely. We do not store credit card details nor have access to your credit card information.

Features

  • 300W Solar Array: Includes three 100W monocrystalline solar panels, producing approximately 1.1kWh of energy per day under 4 peak sun hours.
  • 12V Solar Charging System: Designed around a 12V solar charging system for compatible battery banks.
  • 40A MPPT Charge Controller: Maximizes solar harvest with up to 99% MPPT tracking efficiency and 98% peak conversion efficiency.
  • Solar Charging Kit: Includes professionally matched solar panels, an MPPT charge controller, and installation accessories for efficient battery charging.
  • Versatile Applications: Ideal for RVs, trailers, boats, cabins, and other small off-grid solar charging systems.

Kit Includes

  • 3 x MEGA 100 12V 100W Solar Panels (RS-M100)
  • 1 x 40A MPPT Charge Controller (RS-MPPT40P)
  • 1 x 20 ft 10 AWG Solar Cable (Red), connects solar panel to controller (RS-20101)
  • 1 x 20 ft 10 AWG Solar Cable (Black), connects solar panel to controller (RS-20101)
  • 1 x 10 ft 8 AWG Battery Cable (Red), connects controller to battery (RS-810)
  • 1 x 10 ft 8 AWG Battery Cable (Black), connects controller to battery (RS-810)
  • 3 x Mounting Z Bracket sets (one set of 4) (RS-ZB4C)
  • 1 x 10A Inline Fuse Holder with Fuse(RS-SC10F)

  • MEGA 100

    100 Watt Solar Panel

    The MEGA 100 is the perfect option for any off-grid application. Ideal for anything from RVs to cabins and built to withstand the toughest climates, the MEGA 100 can handle whatever you throw at it.Ā

    • No. of Panels: 3 x MEGA 100 Watt Solar Panels
    • Wattage Per Panel: 100W
    • Total Wattage of Panels: 300W

    Features:

    • 12V off-grid solar panel.
    • 0~+5W guaranteed positive power output.
    • IP67-rated.
    • Built with strong tempered glass and aluminum frame.
    • Certified to withstand challenging environmental conditions.
    • Excellent low light performance on cloudy days, mornings and evenings.

    Installation:

    • Easy installation and handling for various applications.
    • Pre-drilled holes compatible with ground mounts, Z-brackets, pole mounts and tilt mounts.
    • Compatible with on-grid and off-grid inverters.

    Warranty:

    • 25-year output warranty.
    • 10-year workmanship warranty.

    Specifications:

    • Maximum Power(Pmax): 100W
    • Maximum Power Voltage(Vmp): 18.6V
    • Maximum Power Current(Imp): 5.38A
    • Open Circuit Voltage(Voc): 22.8V
    • Short Circuit Current(Isc): 5.78A
    • Maximum System Voltage(Vmax): 1000VDC
    • Weight: 13.2 lb
    • Maximum Series Fuse Rating: 15A
    • Dimensions: 39.0 x 21.3 x 1.2 in

  • BRAVO 40

    40 Amp MPPT Solar Charge Controller

    Features:

    • MPPT
    • Tracking Efficiency Above 99.5%
    • Charge Conversion Efficiency as high as 98%
    • 12V/24V DC System Self-Adaptation
    • Reverse Discharge Protection
    • Targeted for Accuracy
    • Overvoltage Protection
    • Common Negative Connection
    • Charging Data Storage
    • Conformal Coating For Inside Board
    • Designed According to UL1741, EN/IEC 62109 1
    • In-house Design And Manufacture
    • Extensive Internal Electronics In-Circuit Protections And Safety Protections
    • Targeted For Lead Acid Batteries: Gel, AGM, WET, CRYSTAL, CALCIUM Batteries Type Selections
    • Targeted For Lithium Batteries: LiFePO4, LTO (Lithium Titanium Oxide), LCO Batteries Type Selections

    Warranty:

    • 2-Year Warranty

    Specifications:

    • System Nominal Voltage: 12/24V Auto
    • Max. PV Open Circuit Voltage: 100VDC
    • Charging Technology: MPPT
    • Max PV Charging Current: 40A
    • Max. Recommended PV Input Power: 600 Watt (12V) / 1200 Watt (24V)
    • Battery Type Preset: Crystal, Gel, AGM, WET, Calcium / LCO, LFP, LTO
    • Housing Case Color: Black / Grey
    • IP Grade: IP43 for Inside PCBA, IP22 for Connection Area
    • Net Weight: 1.17kg / 2.58lb
    • Dimensions (L*W*H): 195*142*74 mm / 7.7*5.5*2.9 in

Customer Reviews

Overall rating: 5.0 / 5 from 2 reviews.

Customer photo review of 300 Watt Solar Kit

I found a great spot to keep my boat, but there wasn't any power at the dock. At the time, it needed a new shaft seal, so the boat was perpetually slowly sinking and needed the bilge pump to come on every 15 minutes or so. The 300 watt solar system keeps two deep cycle batteries at 14.4 volts all day now that the shaft seal is fixed and the pump doesn't run, and it kept the batteries at 13+ volts all day when the pump was always running. Now I can go anywhere and do anything I need to without fear of losing power. I will upgrade to 600 watts at some point, but for now, I'm very happy with the system. Installation is very easy. It's really just plug and play. After the panels are mounted, it's easier than installing a marine radio. Highly recommended.

David M. 5/5 Verified

300 Watt Solar Kit

Quality products and a friendly staff. All the parts needed were included in this kit.

Mike F. 5/5 Verified

300 Watt Solar Kit
